| Model NO. |
VSA04 |
| Camera |
|
| Image Sensor |
1/3″ color CMOS Sensor |
| Resolution |
4MP |
| Effective Pixels |
2560(H)*1440(V) |
| Compression |
H.264/H.265 |
| Electronic Shutter Time |
Auto（1/1.5s~1/30000s ） |
| Minimun Illumination |
0.01 Lux |
| S/N Ratio |
46dB |
| Scanning System |
Progressive |
| Video Output |
Wireless network |
| Reset Button |
YES |
| PTZ |
|
| Horizontal Rotation Range |
0~355° |
| Tilt Rotation Range |
0~90° |
| Guard Points |
NO |
| LENS Type |
|
| Focus Length |
3.6mm |
| Focus Control |
Fixed |
| Lens Type |
Fixed |
| Pixels |
4M Pixels |
| Night Vision |
|
| Infrared LED |
2PCS Infrared light + 4PCS White light |
| Infrared Distance |
10M |
| IR Status |
AGC auto control |
| IR Power On |
Auto Control |
| Network |
|
| RJ45 |
NO |
| Protocol |
TCP/IP、UDP/IP、DHCP、MQTT、P2P |
| ONVIF |
NO |
| P2P |
Support |
| 4G |
NO |
| WIFI |
Wi-Fi(IEEE802.11b/g/n), No obstacles 100m Max. 3dbi antena |
| Main Stream |
2560*1440@15fps |
| Sub Stream |
800*448@15fps |
| Smart Phone |
support |
| Camera Features |
| Day/Night |
Color/ B&W (IR-CUT ) |
| Image Config |
YES |
| BLC |
Support |
| 3DNR |
Support |
| WDR |
YES |
| Motion Detection |
Support |
|
|
| Privacy Masking |
YES |
| Recording Mode |
SDcard |
| Language |
Simplified Chinese, English, Japanese, German, Russian, French, Italian, Spanish |
| Function |
|
| Audio |
2-Way Audio (MIC and Speaker) |
| Alarm |
Motion Detection、PIR human body infrared detection |
| SD Card Slot |
Support Max 128G |
| General |
|
| Housing |
plastic,IP65 |
| Bracket |
Support |
| IR Cut Filter |
YES |
| Power |
DC 5V/1.5A or 7.5 W solar panel Battery(12000mAh) |
| Operation Temperature |
-10° ~ 45°C /10% ~ 80% (no condensation) |
| Storage Temperature |
-20°C ~ 60° /0% ~ 90% (no condensation) |
